The master plan, in eight parts.

Site, landscape, buildings, floor plates, circulation, security, sustainability and construction. Each part states what is drawn and, where nothing is drawn yet, says so.

01 Site 02 Landscape 03 Buildings 04 Floor plans 05 Circulation 06 Sustainability 07 Security 08 Construction

01 · Site master plan.

As drawn

Top view site plan of the proposed complex showing the colour coded
facilities, the perimeter road, the parking areas and the single entrance
from John Guise Drive — **Site plan, top view**The complex on its 1.42 hectare site at Section 221, Lot 12, with the single entrance from John Guise Drive at the foot of the drawing and the one way perimeter road running around the buildings.

The site runs to 14,200 m², or 1.42 hectares. It is allocated between a 6,000 m² building footprint, 4,200 m² of landscape and public space at thirty per cent of the site, 2,000 m² of roads and circulation and 2,000 m² of parking.

There is one entrance, from John Guise Drive. There is no direct access to the neighbouring Lot 11, which the plan treats as a security requirement rather than an omission. The site faces Melanesia Haus, the Office of the Prime Minister.

Site allocation

Total site area 14,200 m²

Buildings 6,000 m²

Landscaping and public space 4,200 m²

Roads and circulation 2,000 m²

Parking areas 2,000 m²

As drawn

Dimensioned or labelled in the architectural masterplan.

Project intent

Set out in the project brief. Not yet designed or dimensioned.

02 · Landscape master plan.

As drawn

Six landscape zones are drawn and given areas, running to 4,200 m² between them. The planting palette is named but not keyed to positions, so the schedule below is a zone schedule rather than a planting drawing.

01Entrance PlazaEntrance signage and water feature, drop off and seating, flower gardens.800 m²

02Pacific Nations Flag PlazaEighteen Pacific and partner nation flags. Ceremonial and welcome space.500 m²

03Pavilion GardenTrees, palms and tropical planting, with seating and stone pathways.1,000 m²

04Cascade and Reflection PoolThe 16 metre cascade, the reflection pool and the night lighting.700 m²

05Cultural WalkwayA landscaped pedestrian promenade with sculpture and art displays, connecting the major facilities.600 m²

06Performance GardenAn outdoor performance space for traditional and cultural events. Capacity around 200 persons.600 m²

Named planting palette

Royal palm

Traveller's palm

Frangipani

Heliconia

Hibiscus

Bougainvillea

Orchids

Bamboo

Croton

Ixora

Bird of paradise

03 · Building master plan.

As drawn

Two pavilions sit either side of a junction the plan calls The Confluence. Wing A is the Papua New Guinea Pavilion, Wing B the South Pacific Islands Pavilion. The Expo Hall and Cultural Pavilion carry the exhibition and cultural programme, and a curved training wing and an administrative and lodging plate carry the Academy.

The roof motif across the complex is the haus tambaran raked gable, the Melanesian spirit house form. National Parliament House, a short distance away in the same quarter, is itself haus tambaran influenced.

The internal programme of the Expo Hall and the Cultural Pavilion is set out in the project brief and has not been dimensioned. There is no floor plan of either building, and none is presented here as though there were.

The Expo and Convention Centre →

Aerial visualisation of the whole proposed complex showing both pavilions,
the training wing and the cascade — Architectural visualisation · proposed · the complex from the north east

Space Use as drawnArea Capacity

T1–T4 Training rooms Financial literacy and eco tourism workshops 125 m² each · 12.5 × 10.0 m 50 delegates each · 200 total

T5 Digital Innovation and Agritech Testing Lab Commodity tracing, e-commerce, customs simulation 240 m² · 20.0 × 12.0 m Not stated

A1 Admin, shared workspaces and boardroom Consortium, PPP oversight, visiting auditors 200 m² · 20.0 × 10.0 m Not stated

L1 Silver Ambassadors executive lodging suites Senior advisors on short term residency 75 m² each · 450 m² total 6 one bedroom suites

04 · Floor plans.

As drawn

Two floor plates are drawn and labelled. They are reproduced here at the size the source drawing supports. The Expo Hall and the Cultural Pavilion have no floor plan at this stage.

Floor plan of the curved training centre wing with rooms tagged T1 to T5
and a 62.5 metre overall dimension — **Training Centre wing**Five rooms across a 62.5 by 20.0 metre curved plate. Four are training rooms at 125 m² seating 50 delegates each. The fifth, T5, is the digital innovation and agritech testing lab.

Floor plan of the admin and lodging plate showing the A1 workspace and the
L1 executive suite units — **Admin and lodging plate**The A1 shared workspace and boardroom alongside the Silver Ambassadors executive lodging suites. The suite schedule gives six units at 75 m² each.

05 · Traffic circulation plan.

As drawn

One entrance, one direction, one exit. The circulation plan is the most fully resolved part of the masterplan, and it is built around a single controlled gate rather than convenience.

Entry from John Guise Drive

All vehicles enter through the one main gate. There is no second entrance.

Security check

Every vehicle and visitor passes the security gatehouse before entering the site.

Visitor drop off

Visitors are set down at the entrance plaza, with short term parking alongside.

One way circulation

Vehicles move around the complex in one direction only, reaching every parking class in turn.

Exit to John Guise Drive

Vehicles leave by the designated exit lane. A separate lane carries service and emergency access.

Parking allocation

Visitor parking120 lots

VIP parking20 lots

Tourist bus parking10 lots

Staff parking30 lots

Service vehicle parking10 lots

Total190 lots

The ten tourist bus lots are the coach provision for the Maritime Tourism Plaza.

Visualisation of the visitor drop off area at the entrance plaza — Architectural visualisation · proposed · visitor drop off

06 · Sustainability features.

As drawn

The complex is specified to a net zero operating standard. A 1.2 MW roof solar canopy feeds a 2.5 MWh lithium iron phosphate battery vault, which carries the site through the evening. Connected operating load is 237 kW: 220 kW of pumping, 15 kW of illumination and 2 kW of control automation.

Water is closed circuit. 180,000 litres recirculate at 450 litres per second over a 16 metre gravity fall, returning by gravity into a sub surface bio retention sand filtration basin. Rainwater harvesting, smart irrigation, LED lighting, EV charging and waste recycling are specified alongside.

The full operating cycle

Energy and water schedule

Roof solar canopy1.2 MW

Battery vault2.5 MWh LFP

Connected operating load237 kW

Recirculating water volume180,000 L

Flow rate450 L/s

Gravity fall16 m

Rainwater harvestingSpecified

Smart irrigationSpecified

EV charging stationsSpecified

LED lightingSite wide

Bio-retention sand filtrationSub surface

Waste management and recyclingSpecified

Design parameters, not live telemetry

07 · Security master plan.

As drawn

Security follows from the circulation decision. Because there is one entrance, there is one point at which every vehicle and every visitor is checked, and the gatehouse sits on it. Diplomatic and VIP access is controlled separately at the entrance and at The Confluence.

The measures below are named in the masterplan. No security contractor, system supplier or operating procedure has been appointed, and none is named here.

Measures named in the plan

24 hour security gatehouseAt the single entrance

CCTV surveillanceSite wide

Access control and visitor registrationAt the gatehouse

Perimeter fencing and night lightingFull perimeter

Emergency call pointsAcross the site

Emergency and service access laneSeparate from visitor flow

Diplomatic and VIP access controlEntrance and The Confluence

No direct access to Lot 11Full independence from the neighbouring lot

08 · Construction phases.

Not yet programmed

There is no construction phasing plan. No staging drawing, no programme, no sequence, no start date and no completion date has been prepared for this project. The project brief lists construction phasing as part of the technical package, and it will be issued when it is drawn.

Publishing a phasing chart the project does not have would be the easiest page on this site to fill and the one most likely to be tested. So this section says what is true instead: the masterplan is complete, the project is at partner and investment engagement stage, and phasing will be programmed with the appointed delivery partner.

Partnership and delivery tracks →

Where the project stands

Complete Site identified
Complete Masterplan complete
Now Partner and investment engagement
Not programmed Detailed design
Not started Construction
